Eaton EMCH116 16A, 10kA, Type C Single Pole MCB

Product Description



• Terminal Type: Box clamp



• Current Rating: 16A



• Tripping Characteristics: Type C



• Breaking Capacity at Maximum Voltage Rating: 10 kA



• Reset Actuator Type: Toggle Switch




• Break Time: Instantaneous



• Terminal Capacity: 1 -25mm²



• Terminal Screw: M5 Combination



• Terminal Torque: 2.0Nm - 2.4Nm max



• Mounting: DIN rail



• Degree of Protection: IP20



• Positive Contact Indication: Red/Green flag indicator



• Rated Volume: 230/240 V AC, 48V DC (per pole)



• Rated Impulse and Withstand VOltage: 4kV (1.2/50) u sec



• Rated Short Circuit Capacity: 10kA to IEC EN 60898 and 15kA to IEC EN 60947-2



• Selectivity Class: 3 to EN 60898



• Instanteneous Tripping Current: 3 In < Imt< 5 In



• Conventional Non-Tripping Current: I nt = 1.45 In



• Ref/Calibration Temperature: 40° C



• Number of Operating Cycles Elec: >4000



• Number of Operating Cycles Mech: >2000
